Quick Details

  • Place of Origin: Hubei, China (Mainland)
  • Brand Name: Hubei Qixing
  • Model Number: QXC5030XLJ
  • Color: White

Packaging & Delivery

Packaging Details: Bulk or as customers needs
Delivery Detail: 30 days after deposit

TRUCK CAMPER(Pick-up caravan)







lightspot



A. Fresh and shining sofa bed



 B. Simple fashion style and with all  Living facilities

C. Caravan special outdoor gas cooker


D. Large double bed

E. Portable toilet and shower room

Main Parameter

Model No.:

QXCS5030XJL

Rated Pessenhers

5

Outer Dimension(mm):

5685*2050*2200

The internal Height OThe

Caravan after Expansion(mm):

1985

Wheel Base(mm):

3095

Driver's License Requirements:

C1

Front/Rear suspension(mm):

905/1685







Engine

Engine Type:

4JK1

Tire:

245/70R16

Volume(L):

2.5T

Approach/Departure Degree:

25/18

Max Power(kw/rpm):

100/3600

Axle Weight(kg):

1235/1575

Max Torque(N.m/rpm):

320/1800-2800

Max Total Mass(kg):

2810

Max Speed(kw/h):

120

Gross Weight(kg):

2485

Fuel Emission Standard:

Diesel/Euro4

Front/Rear Suspension(mm):

1570/1570

Driving Mode:

Pre/4-Wheel Drive

Min Ground Clearance(mm):

205

Oil Consumption:

8.8



Main Configuration

1.Al-Alloy body+sandwich composite plate

20.Caravan special Refrigerator(48L)

2.DC four column synchronous electric lift cylinder (600mm travel)

21.DVD+GPS+Reverse image integrated machine

3.Folding outdoor waterproof insulation curtain

 (including windows and ventilation screen window)

22.24 inch flip TV

(with USB function)

4.Single opening rear door (with screen door)

23.CMMB Television receiving system

5.Side sliding window(with curtian and screen)

24.LED lamp belt around the car

6.Body appearance is white with colour bar painting

25.90L double temperature water purification tank

7.outer storage bin

26.30L Sewage tank

8.Wall and sofa embellish Environmental leather

27.External water tap

9.Sitting type double sofa

(Sofa can be assembled into bed 1100*1850)

28.Caravan special hot and cold pump

10.Lifting table(with folding)

29.Whole vehicle water pipe system

11.Fancy wood floor

30.Caravan special water inlet

12.The high-end cabinet table board,composite shape of cabinet and locker

31.15m external water injection pipe

13.triple bed on the top of the cab.(1700*1900

32.Water thermal insulation system

14.Caravan special zip mode  showe

33.The built-in faucet and shower(can be hung)

15.Portable toilet

34.2000W charging inverter integrated machine

16.Portable outdoor gas cooker

35.200Ah LFP battery

17.Electric transmission ventilation window with turning function

36.220V city electric fast interpolation,15m external cable

18.Caravan special skylight

37.Caravan central control system

19. floor air conditioner with Cold and warm integrated

38.2.5M sunshade(including Outdoor lighting lamp)



  Detailed Picture
