Quick Details

  • Condition: New
  • Storage: Oil
  • Horsepower: 351 - 450hp
  • Transmission Type: Manual
  • Fuel Type: Diesel
  • Tank Volume: > 30000L
  • Dimensions (L x W x H) (mm): 11900MMx2500MMx3900MM
  • Brand Name: QIXING
  • Place of Origin: Hubei, China (Mainland)
  • Model Number: QXAFT001
  • Gross Vehicle Weight: 40000
  • Certification: DOT,SANO,CE,ASME,ISO9001, CCC, ISO/TS16949, SGS
  • Material: Aluminum alloy
  • Axle Brand: BPW
  • Suspension System: Air Suspension
  • ABS Anti-lock Braking System: Equipped
  • Volume: 28000L to 48000L
  • Differential Gear Type: Anti-slip Type
  • Universal Joint Type: Flexible Universal Joint
  • Export Markets: Eastern Europe, Southeast Asia, Africa, Mid East, Eastern Asia

Packaging & Delivery

Packaging Details: per requirement
Delivery Detail: 30 days after order confirm

3axle  from 28000liters to 48000liters  Aluminum Alloy Fuel Tanker Semi-trailer



TECHNICAL DETAILS
CapacityFrom 28.000 L to 48.000 L
Construction- Light aluminium tank, coffer-shaped or cylindrical;
- Self-supporting construction. For off-road only coffer-shaped tanks and a steel chassis frame
ADRConstruction in accordance with ADR regulations for fuel transport cat.3
MaterialAluminium X-TRAL 728 in accordance with DIN
CompartmentsTank divided into 1 to 8 compartments
WeldsSupporting welds are given a radiographic check (10%)
Equipment for every compartmentEvery compartment has a manhole, manhole flange, as well as a bottom valve flange
Additional equipment- Anti-slip cover over the whole tank, or a walkway in case the tank is cylindrical;
- 2 drains at the rear of the tank that run through the inside of the tank;
- Aluminium ladder with anti-slip rungs;
- Collapsible railing on top of the tank;
- Compartments for hoses over the entire length of the tank (1 on every side)
Fittings on top of tank (every compartment)1 manhole cover DN 500 mm z with a DN 250 inlet, opening opposite to the driving direction
Fittings for unloading- Fittings for unloading are located in a closed aluminium cabinet with aluminium doors;
- Release pipe DN 100 leading from the bottom valve on the right side of the vehicle;
- Release valve DN 100 for gravity discharge
Unloading possibilitiesGravity discharge without measuring equipment
Chassis- The axle supporting elements are protected against corrosion;
- BPW or SAF axles with pneumatic suspension;
- Options: lift axle, self-steering axle;
- Disc brakes or drum brakes;
- Accepted load per axle: 9 ton
- ABS system with 4 sensors.
Wheels and tyres6 or 7 wheels and tyres (incl. spare wheel)
Tyres 385/65 R 22.5
Pneumatic air compression system- Brake blocks and shoes asbestos free;
- Double wire braking system with automatic slack adjustment (wireless);
- The brake pressure is automatically adjusted to the load;
- Membrane braking cylinder;
- EBS system – HALDEX or WABCO, model 4S/2M, model 2S/2M or 4S/3M
Mudguards6 plastic - polyamide mudguards, equipped with splash guards on the rear axle
Additional equipment1 bumper with built-in electric lighting in aluminium;
2 chocks (wedges) in holders
Electrical installation- 24V, 15-pin connection plug, or 2x7-pin connection plug, in accordance with ADR regulations;
- Electrical equipment with anti-explosion safety;
- The connection cable between the tractor and the semitrailer is not included;
- Rear lighting consisting of 5 parts: Braking lights, indicator lights, fog lights, reversing lights and running lights;
- Side outline with LED lights;
- License plate light;
- Reflectors on the rear of the tank;
- 2 outline lights at the end of the bumpers
Accessories- 12 kg fire extinguisher;
- Fire extinguisher in plastic cover;
- 2 grounding bolts and 1 reel, manually operated with a grounding cable of 15 m;
- Board with product indication;
- Equipment in accordance with ADR regulations;
- Manual and scheme of unloading fittings.
PaintingBefore painting, the aluminium elements are etched, then painted with a primer and then painted with a high-quality two-component acrylic paint. Colour according to client’s wishes.
Extra- Water tightness test of tank and fittings;
- Check of unloading fittings;
- All certificates and manual concerning bottom loading, unloading and the vapour recovery system



 Product Sample

Certifications



Production Machinery

Welcome to our factory !

Our long-term cooperation parters

If have interest, please contact me!!!
